40G AOC Copper 1-10m QSFP To QSFP Active Optical Cable Custom

Product Description

40G AOC Copper 1-10m QSFP To QSFP Active Optical Cable

QSFP active optical cables are a high performance, low power consumption, long reach interconnect solution supporting 40G Ethernet, fiber channel and PCIe. It is compliant with the QSFP MSA and IEEE P802.3ba 40GBASE-SR4. Fiberise QSFP AOC is an assembly of 4 full-duplex lanes, where each lane is capable of transmitting data at rates up to 10Gb/s, providing an aggregated rate of 40Gb/s.

Features

• Full duplex 4 channel 850nm parallel active optical cable
• Transmission data rate up to 10.3Gbit/s per channel
• SFF-8436 QSFP+ compliant
• Hot pluggable electrical interface
• Differential AC-coupled high speed data interface
• Multi-mode optical fibre cable of up to 100m
• 4 channels 850nm VCSEL array
• 4 channels PIN photo detector array
• Management Interface and digital diagnostic monitoring through I2C
• Low power consumption
• Housing isolated from connector ground
• 3.3V power supply voltage
• Operating case temperature 0°C to +70°C

Specifications

• Length: 10 Meters
• Connector A: QSFP Active
• Connector B: QSFP Active
• Channels: 4 Lanes, bi-directional
• Data Rate: 1 to 10.3125 Gbps/channel
• Cable Type: SMF(Single Mode Fiber)
• Supply Voltage: 3.1 to 3.5V
• Storage Temperature: -20 to 85 ºC
• Operating Temperature: 0 to 70 ºC
• Humidity (non-condensing): 5% to 95%

Applications

• InfiniBand SDR, DDR, QDR
• Hubs, switches, routers, servers
• Ethernet 10G,40G
• 4-channels 10Gb Ethernet or 8.5Gb Fiber Channel transmission
• SAS, SATA 3G, 6G
• Fibre Channel SAN 10G,20G, 40G
• Myrinet 40G
• Optical Backplanes
• Rack-to-Rack, Shelf-to-Shelf Interconnect
• Proprietary Cluster Interconnect
• Data Centers

Standards Compliance

• SFF-8431
• SFF-8436
• FCC Class B
• EN55022: 2006 (Class B)
• EN/IEC 61000-4-3
• Safety: UL, CSA, CE
• RoHS 6
