• 2.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver
  • 2.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver
  • 2.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver
2.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver

2.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver

Product Details:

Place of Origin: China
Brand Name: Hilink
Certification: CE,ROHS,FCC
Model Number: HL-2.5GBASE-T Copper SFP

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Static bag, Plastic Flat, Retail box, by requires
Delivery Time: 5-8workingdays
Payment Terms: L/C, Western Union, T/T
Supply Ability: 10000pcs/month
Get Best Price Contact Now

Detail Information

Products Name: 2.5GBASE-T Copper SFP Transceiver Daterate: 2.5G
Connector: RJ45 Operating Temperature: 0°C To +70°C
OEM: Support OEM Warrnty: 3years
Power: 3.3V Power Supply Compatible: 2.5Gbase-T / 1000base-T/100base-T Standards
High Light:

MSA Copper SFP Transceiver

,

2.5GBASE-T Copper SFP Transceiver

,

Lead Free SFP RJ45 Transceiver

Product Description

2.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver

2.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver



  • Support 2.5Gbase-T / 1000base-T/ 100base-T on line port
  • Support 2.5Gbase-X on host port
  • Hot-pluggable SFP footprint
  • Compact RJ-45 connector assembly
  • RoHS compliant and lead-free
  • Single +3.3V power supply
  • 2.5 Gigabit Ethernet over Cat 5 cable
  • Ambient Operating temperature: 0°C to +70°C
  • Power dissipation <2W



  • PRODUCT DESCRIPTION

  • SFP-2.5GBASE-T-A Copper Small Form Pluggable (SFP) transceivers are based on the SFP Multi Source Agreement (MSA) They are compatible with the 2.5Gbase-T / 1000base-T/100base-T standards as specified in IEEE Std 802.3.SFP-2.5GBASE-T-A uses the SFP's RX-LOS(must be pulled up on host) pin for link indication. If pull up or open SFP's TX-DISABLE pin, PHY IC be reset.

  • Cable Length

    Line Port Host Port Cable Reach
    2.5Gbase-T 2.5Gbase-X CAT5E 100m
    1000base-T 2.5Gbase-X CAT5E 100m
    100base-T 2.5Gbase-X CAT5E 100m



    In the ingress direction, the entire packet is fully buffered prior to being transmitted out of Host port at 2.5Gbps. In the egress direction, the 2.5Gbps packet is buffered since the line port at a slow speed, the egress packet should be throttled to match the lower speed by extending the IPG between packet. flow control can be enabled on the host side MAC to limit the flow of packets.2.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver 02.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver 12.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver 22.5GBASE-T Copper SFP Transceiver Sfp Copper SFP RJ45 Copper Transceiver 3



    一 OEM and ODM

    OEM/ODM order is available.

    Guarantee
    We promise all the advertised optical transceivers are brand new with new components and parts and absolutely never use old and refurbished materials. All the optical transceivers have been through functional test and aging test. We provide 3 years warranty for all the optical transceivers from the date of shipment.



    What we supply

    We supply all kinds of compatible optical transceiver modules, including SFP, GBIC, SFP+, XENPAK, X2 , XFP, BIDI,CWDM,DWDM and other special transceiver modules. Our products are compatible with most of brands. If more details, please contact us.



    FAQ

    Q:Do you sell second-hand products?

    A:No.All our products are brand new,we never use second-hand components.



    Q:What payment terms do you accept?

    A:T/T,Paypal,Western Union are acceptable.



    Q:What are the shipping ways can you offer?

    A:Our usual shipping ways are DHL,FedEX,TNT,UPS,EMS etc.It will take 3-7days.



    Q:Do your products come with warranty?

    A:Yes,We provide 3 years warranty for all our products from the date of shipment.



    Q:What devices can your products compatible with?

    A:Our products are compatible with Mainstream switches.



    Q:How to place an order?

    A:1>Order details confirmed,please tell us the model and quantity you need.
    2>Proforma Invoice confirmed, the order will be arranged upon receipt of your payment.
    3>Confirm and ship the goods, then tracking number will be sent to you promptly.
    4>We will help to track your goods until you receive them safely.

  •
