Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | HILINK |
| Certification: | CE FCC Rohs |
| Model Number: | HL-SFP10G-80 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1pcs |
| Price: | Negotiable |
| Packaging Details: | Carton box, Retail box, Or by required |
| Delivery Time: | 1-6 days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 3000 pcs per Week |
|
Detail Information |
|||
| Data Transfer Rate: | 10GBASE-ZR-80km | Distance: | 80km |
|---|---|---|---|
| Wavelength: | 1550nm | Interface: | Duplex LC Connector |
| Warranty: | 3 Years | Certification: | CE FCC |
| High Light: | 80KM LC SFP+ Transceiver Module,1.5W SFP+ Transceiver Module,EML Single Mode Sfp Module |
||
Product Description
10G 80km ZR 80km SFP Compatible Brand 10GBASE SFP 1550nm ZR 80KM LC SFP+ 80KM
HILINKs’ HLSP551XL-C(I)D80 transceivers are Enhanced Small Form Factor Pluggable SFP+ transceivers designed for use in 10-Gigabit multi-rate links up to 80km of G.652 single mode fiber. They are compliant with SFF-8431, SFF-8432 and support 10G Ethernet ZR and 10G Fibre Channel.Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472. The transceiver designs are optimized for high performance and cost effective to supply customers the best solutions for telecommunication and datacom.
Features:
Supports 9.95 to 11.3Gb/s bit rates with Dual CDR
Duplex LC connector
Hot pluggable SFP+ footprint
Cooled 1550nm EML transmitter, APD receiver
Applicable for 80km SMF connection
Low power consumption, < 1.5W
Digital Diagnostic Monitor Interface
Optical interface compliant to IEEE 802.3ae 10GBASE-ZR
Electrical interface compliant to SFF-8431,SFF-8432
Operating case temperature:
Commerical:0 to 70 °C
Industrial:-5 to 80 °C
Applications:
10GBASE-ZR at 10.3125Gbps
OTN G.709 OTU1e/2/2e
4x, 8x and 10x 10G Fiber Channel
Other optical links
10G Transceiver:
| SFP-10G-MM-SR | 10G | 850nm | 300M | 0~70 |
| SFP-10G-LR | 10G | 1310nm | 10KM | 0~70 |
| SFP-10G -ER | 10G | 1550nm | 40KM | 0~70 |
| SFP-10G-ZR-80 | 10G | 1550nm | 80KM | 0~70 |
| SFP-10G-ZR-100 | 10G | 1550nm | 100KM | 0~70 |
| SFP-10G-ZR-120 | 10G | 1550nm | 120KM | 0~70 |
Product Show:
