Name: 40G QSFP+ Transceiver 100km LC Duplex RoHS Compliant
Brand: Shenzhen HiLink Technology Co.,Ltd.
SKU: HL-QSFP-40G-ZR4
Price: 1,310.00 USD
Availability: InStock

Home > products > QSFP+ Transceiver >

40G QSFP+ Transceiver 100km LC Duplex RoHS Compliant

40Gb/s QSFP+ optical transceiver 100km

QSFP+ transceiver C Band EML APD

40G Ethernet transceiver LC connector

Place of Origin:

Guangdong, China

Brand Name:

HILINK

Certification:

CE FCC Rohs

Model Number:

HL-QSFP-40G-ZR4

Request A Quote

40G QSFP+ Transceiver 100km LC Duplex RoHS Compliant

Product Details

Products Name:

40G QSFP+ 100Km

Connetor:

Duplex LC

Data Rate:

40G

Distance:

100KM

Temperature Range:

0℃ ~ +70℃

Certification:

RoHS Compliant

Type:

Fiber Optic Transceivers, 40G QSFP+

Digital Diagnostic Functions:

Built-in

Payment & Shipping Terms

Minimum Order Quantity

1pcs

Price

EXW: 1280~1340USD/PCS

Packaging Details

Static bag, Plastic Flat, Retail box, by requires

Delivery Time

5-8workingdays

Payment Terms

Western Union,T/T,L/C

Supply Ability

100pcs/month

40G QSFP+ 80km Duplex LC Single Mode Optical Transceiver

Get Best Price

100Gb/s QSFP28 LR4 Optical Transceiver Module 20KM Hot Pluggable Duplex LC Connector Single Mode RoHS Compliant

Get Best Price

Video

800G DR8+ 1310nm 2km OSFP Optical Module OSFP112 Dual MPO-12 connector for Data Center

Get Best Price

QSFP200G QSFP56 200G SR4 Hot Pluggable Optical Transceiver 70m@OM3 100m@OM4 FEC Single MPO12 Multimode Fiber RoHS complaint High Speed for 200GBASE-SR4 Ethernet links Data centers

Get Best Price

86-755-8317-6243

Contact Now

Product Description

40Gb/s QSFP+ 100km Optical Transceiver

Hot Pluggable C Band EML APD Duplex LC Connector Single mode DDM RoHS Compliant for 40G Ethernet

Product Features

4 lanes MUX/DEMUX design
Integrated DWDM TOSA/ROSA for up to 100 km reach over SMF
C Band EML transmitter, APD photo-detector
Duplex LC connector
Up to 11.2Gbps per channel bandwidth
Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-EZR4
Single +3.3V power supply operating
Built-in digital diagnostic functions
Temperature range 0°C to 70°C
Compliant with QDR/DDR Infiniband data rates
QSFP MSA compliant
RoHS Compliant Part

Applications

Rack to rack connections
Data center switches and routers
Metro networks
40G BASE-EZR4 implementations

Product Description

The HL-QSFP-40G-ZR4 is a transceiver module designed for 100km optical communication applications. The design is compliant with 40GBASE-EZR4 of the IEEE P802.3ba standard. The module converts 4 input channels of 10Gb/s electrical data to 4 DWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. On the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 DWDM channel signals, and converts them to 4 channel output electrical data.

The central wavelengths of the 4 DWDM channels are members of the DWDM wavelength grid. It contains a duplex LC connector for the optical interface and a 38-pin connector for the electrical interface. Single-mode fiber (SMF) must be used with this module to minimize optical dispersion in long-haul systems.

Our Service

OEM and ODM: OEM/ODM orders are available for custom requirements.

Quality Guarantee

We guarantee all advertised optical transceivers are brand new with new components, never using old or refurbished materials. All units undergo functional and aging tests. We provide a 3-year warranty from the shipment date.

Product Range

We supply compatible optical transceiver modules including SFP, GBIC, SFP+, XENPAK, X2, XFP, BIDI, CWDM, DWDM and special transceiver modules. Our products are compatible with most major brands. Contact us for detailed compatibility information.

Packaging & Shipping

We ship internationally via DHL, FedEx, EMS, TNT, UPS and other carriers. Typical delivery time is 3-7 days.
