SFP-10G-LRM Fiber Channel SFP Gigabit Ethernet Transceiver 1310nm 220M

SFP-10G-LRM Fiber Channel SFP Gigabit Ethernet Transceiver 1310nm 220M

sfp+ optical transceive

10g sfp+ module

Place of Origin:

China

Brand Name:

HILINK

Certification:

CE FCC Rohs

Model Number:

HL-SFP-10G-LRM

Contact Us
Request A Quote
Product Details
Wavelength:
1310nm
Data:
10Gbs
Distance:
220M
Package:
SFP
Media Type:
MMF
Connector:
Dual LC
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
Negotiable
Packaging Details
Blister Packaging
Delivery Time
3-5 Working Days
Payment Terms
T/T, Western Union
Supply Ability
100PCS Per Day
Product Description

SFP-10G-LRM Fiber Channel SFP Gigabit Ethernet Transceiver 1310nm 220M



 Hilink SFP-10G-LRM supports 10GBASE Ethernet and OTU2/OTU2e

Hot-swappable input/output device that plugs into an Ethernet SFP+ port of a switch.

It provides flexibility of interface choice .

Supports "pay-as-you-populate" model. Supports digital optical monitoring DDM

Optical interoperability with 10GBASE XENPAK, X2, and 10GBASE XFP interfaces on the same links



Features:



♦ Optical interface compliant to IEEE 802.3ae

Electrical interface compliant to SFF-8431

Hot Pluggable 10Gbase

1310nm FP transmitter, PIN photo-detector Operating case temperature: 0 to 70 °C

Low power consumption

Applicable for 220m MMF connection

All-metal housing for superior EMI performance

Advanced firmware allow customer system encryption information to be stored in transceiver

Cost effective SFP+ solution, enables higher port densities and greater bandwidth



Product Details

Item No. SFP-10G-LRM Vendor Name Hilink
Form Type SFP+ Max Data Rate 10Gbps
Wavelength 1310nm Max Cable Distance 220M
Interface LC duplex Optical Components FP 1310nm
Cable Type MMF DOM Support Yes
TX Power -6.5~-0.5dBm Receiver Sensitivity < -10dBm
Commercial Temperature Range 0 to 70°C (32 to 158°F) HTS-Harmonized Code 8517706000

Applications

l High-speed storage area networks

l Computer cluster cross-connect

l Custom high-speed data transfer link




Our  SFP package

SFP-10G-LRM Fiber Channel SFP Gigabit Ethernet Transceiver 1310nm 220M 0
