Shenzhen HiLink Technology Co.,Ltd.

MMF Dual LC Optical Transceiver Module 100G QSFP28 SWDM4 850 - 940nm 4 Channels 4x25G

Product Details:
Place of Origin: China
Brand Name: HILINK
Certification: CE FCC RoHS
Model Number: HL-Q28-100G-SWDM4
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Blister Packaging
Delivery Time: 3-5 Working Days
Payment Terms: T/T, Western Union, MoneyGram,Paypal
Supply Ability: 100PCS Per Day
  • Detail Information
  • Product Description

Detail Information

Product Name: 100G QSFP28 SWDM4 MMF Transceiver Data Rate: 100GE
Wavelength Region: 850-940nm Reach Distance: 150M Max Over OM5
Connector: LC Dual DDM: Yes
High Light:

Dual LC Optical Transceiver Module

,

SWDM4 Optical Transceiver Module

,

4 Channels 100G QSFP28 Transceiver

Product Description



100G QSFP28 SWDM4 850~940nm 4 Channels 4*25G MMF Dual LC Optical Module



Hilink 100G QSFP28 SWDM4 transceiver modules are designed for use in 100G Ethernet links over duplex multimode fiber. Four channels/lanes in the 850-940nm region @ 25.78Gbps to transport the Ethernet signal. Digital diagnostics functions are available via an I2C interface, as specified by the QSFP28 MSA.



Item No. HL-Q28-100G-SWDM4 Vendor Name Hilink
Form Type QSFP28 Max Data Rate 100Gbps
Wavelength 850~940nm Max Cable Distance 150M
Interface LC Duplex DOM Support Yes
Cable Type MMF Commercial Temperature Range 0 to 70°C (32 to 158°F)


Features



•  Compliant with QSFP28 MSA

•  Compliant with SWDM MSA

•  Compliant with IEEE802.3bm CAUI-4

•  Hot-pluggable QSFP28 form factor

•  4x25Gb/s 850mm VCSEL-based transmitter

•  Supports 103.1Gbps aggregate bit rate

•  Power dissipation<3.5W

•  Maximum link length of 150m on OM5 multimode Fiber

•  Case temperature range of 0°C to 70°C

•  Duplex LC receptacles

•  CAUI-4 electrical interface

•  RoHS compliant





Applications



•  100GBASE Ethernet over Duplex MMF





Compatibility



Hilink optical Transceiver 100% compatibility: Cisco, Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Mikrotik, Finisar, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.




Details Photos


MMF Dual LC Optical Transceiver Module 100G QSFP28 SWDM4 850 - 940nm 4 Channels 4x25G 0

MMF Dual LC Optical Transceiver Module 100G QSFP28 SWDM4 850 - 940nm 4 Channels 4x25G 1MMF Dual LC Optical Transceiver Module 100G QSFP28 SWDM4 850 - 940nm 4 Channels 4x25G 0




Hilink Advantages


1. Hilink ,a professional manufacturer established in 2007,Specialize in optical network communications with over 10 years experience.
2." Credit is the basis, quality is the first",all our products are new,we never use second-hand components.
3. Our optical transceivers are compatible with Cisco,Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, Dlink, Alcatel, Riverstone,
Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc
.
4. We provide 3 years warranty for all our fiber optical products from the date of shipment.
5. All of our QSFP, QSFP28, QSFP56, QSFP-DD
CWDM/DWDM/Bidi SFP/SFP+/XFPAOC/DAC products pass CE,ROHS,FCC.
6. We also provide DWDM CWDM WDM optical solutions.

FAQ


1. Can I have a sample order? What is your MOQ?
Sample order is supported for testing the quality of goods. 1 piece is the MOQ.
Mixed samples are acceptable.


2. What is the lead time?

1-3 days after receiving the payment for the regular goods we normally keeping in stock;
For large quantity, you'll get support and details from your sales representative of HilinkTech.


3. What is the shipping way and how long is the period?

DHL, UPS, FedEx or TNT will be taken according to your option. The arrival normally takes 3-5 days .


4. What is your warranty?

3-year warranty.You'll get technique support, replacement or refund.
