Place of Origin:
Guangdong, China
Brand Name:
HILINK
Certification:
CE FCC Rohs
Model Number:
HL-QSFP28-100G-BXD80
They are compliant with SFF-8665, INF-8438i and IEEE 802.3ba 100GBASE-ZR4. Digital diagnostics functions are available via an I2C interface, as specified by the QSFP28 MSA.
Up to 80km reach for G.652 SMF
Cooled 4x25Gb/s LAN WDM Blue or Red Side TOSA, LAN WDM Red or Blue Side ROSA
4x25G Electrical Interface
Single +3.3V power supply
DDM function implemented
2 Wire Serial Interface for module management
Maximum power dissipation<5.5W
Operating temperature range: 0℃ ~ 70℃
Compliant with RoHS6
100GBASE-ZR4 Ethernet
100G Datacom& Telecom connections
100G 4WDM-40
| HL-QSFP28-100G-SRBD | 100GBASE SRBD 850nm 100M LC |
| HL-QSFP28-100G-BXD10 | 100GBASE BIDI 1331/1271nm 10KM LC |
| HL-QSFP28-100G-BXU10 | 100GBASE BIDI 1271/1331nm 10KM LC |
| HL-QSFP28-100G-BXD20 | 100GBASE BIDI 1310/1280nm 20KM LC |
| HL-QSFP28-100G-BXU20 | 100GBASE BIDI 1280/1310nm 20KM LC |
| HL-QSFP28-100G-BXD30 | 100GBASE BIDI 1309/1304nm 30KM LC |
| HL-QSFP28-100G-BXU30 | 100GBASE BIDI 1304/1309nm 30KM LC |
| HL-QSFP28-100G-BXD40 | 100GBASE BIDI 1309/1304nm 40KM LC |
| HL-QSFP28-100G-BXU40 | 100GBASE BIDI 1304/1309nm 40KM LC |
| HL-QSFP28-100G-BXD80 | 100GBASE BIDI 1280/1300nm 80KM LC |
| HL-QSFP28-100G-BXU80 | 100GBASE BIDI 1300/1280nm 80KM LC |
Mechanical Dimensions
