QSFP28 100G BiDi Optical Transceiver with 10KM Reach 1271/1331nm Wavelength and Simplex LC Interface

QSFP28 100G BiDi Optical Transceiver with 10KM Reach 1271/1331nm Wavelength and Simplex LC Interface

10KM Reach QSFP28 Optical Transceiver

1271/1331nm Wavelength 100G BiDi Transceiver

Simplex LC Interface Single Fiber Transceiver

Place of Origin:

China

Brand Name:

Hilink or Customized

Certification:

CE ROSH FCC UKCA

Model Number:

HL-QSFP-100G-BXU/D10

Contact Us
Request A Quote
QSFP28 100G BiDi Optical Transceiver with 10KM Reach 1271/1331nm Wavelength and Simplex LC Interface QSFP28 100G BiDi Optical Transceiver with 10KM Reach 1271/1331nm Wavelength and Simplex LC Interface
Product Details
Wavelength:
1271/1331nm
Interface:
Simplex LC
Data Speed:
100G
Fiber:
SMF
Reach:
10km
Encoding:
PAM4
DDM/DOM:
Yes
Temperature:
Commercial Temp: 0°~75°
Private Label:
Supported
Payment & Shipping Terms
Minimum Order Quantity
1 pair
Price
Negotiable
Packaging Details
0.02g
Delivery Time
5-8 working days
Payment Terms
L/C,T/T,PayPal
Supply Ability
2000 pairs per month
RELATED PRODUCTS
Good price QSFP28 100G BiDi Optical Transceiver with 10KM Reach 1271/1331nm Wavelength and Simplex LC Interface online

QSFP28 100G BiDi Optical Transceiver with 10KM Reach 1271/1331nm Wavelength and Simplex LC Interface

Get Best Price
Good price 10G DWDM SFP+ Optical Transceiver Module with 80km Distance C17-61 Wavelength and DDM/DOM Support online

10G DWDM SFP+ Optical Transceiver Module with 80km Distance C17-61 Wavelength and DDM/DOM Support

Get Best Price
Good price 10G BiDi SFP+ Optical Transceiver with 1270/1330nm Wavelength and 10KM Distance for Single Fiber Transmission online

10G BiDi SFP+ Optical Transceiver with 1270/1330nm Wavelength and 10KM Distance for Single Fiber Transmission

Get Best Price
Good price 400G QSFP-DD LR4 Optical Transceiver with 10km Transmission 1310nm Wavelength and Duplex LC Connector online

400G QSFP-DD LR4 Optical Transceiver with 10km Transmission 1310nm Wavelength and Duplex LC Connector

Get Best Price
Contact Us
+86 188 7132 7004
sales09@hilinktech.com
86-755-8317-6243
Contact Now
Product Description

100G QSFP28 WDM BIDI 10KM SMF Simplex LC Connector DDM 1271/1331 Commercial Temperature Transceiver Module

Hilink 100G BIDI QSFP28 optical transceiver uses the wavelengths of TX1271nm/RX1331nm with PAM4 signal for up to 10km transmission over single-mode fiber.


Features:

  • QSFP28 MSA package with simplex LC connector
  • Single +3.3V power supply
  • Supports 100GBASE-LR1-BIDI-10km
  • wavelengths of TX1271nm/RX1331nm with PAM4 signals for up to 10km transmission on SMF
  • Lane signaling rate 106.25Gb/s with PAM4,111.8Gb/scompatible
  • EML Laser and PIN receiver
  • Operating case temperature: 0 to +70 °C

Product Details:

Product Name 100G QSFP28 BIDI 10KM
Wavelength 1270/1330
Data Rate 100G
Connector Simplex LC
Transmitter Type EML
Receiver Type PIN
DDM Yes
TX Power -1.4-4.5dBm
RX Sensitivity <-6.1dBm
HS Code 8517795000
Warranty 3 years
Temperature 0-70
