    Product Details:

    Place of Origin: CHINA
    Brand Name: Hilink
    Certification: CE ROHS FCC
    Model Number: 40GBase-ER4

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: Negotiable
    Packaging Details: Blister Packaging, 10pcs/tray
    Delivery Time: 1-6 days
    Payment Terms: T/T, Western Union
    Contact Now
    Detailed Product Description
    Transmitter: CWDM4 Voltage: 3.3v
    Wavelength: 1270-1330nm Diagnostics: Yes
    Connector Type: LC Temperature: 0-70
    Receiver: PIN Distance: 40KM

    40km Hot Pluggable QSFP Optical Module 40GBASE-ER4 1270-1330nm With Dulplex LC



    The 40G QSFP ER4 optical transceiver integrates the transmit and receive path onto one module. Four electric-absorption modulated lasers (DFBs) with 1271, 1291,1311 and 1331 nm center wavelengths, which multiplexed/demutiplexed into a single-mode fiber through an industry-standard LC connector. Each data steam is recovered by a PIN photodetector and transimpedance amplifier, retimed, and passed on to an output driver.



    Features:
    4 CWDM channels are 1271, 1291,1311 and 1331 nm
    Single +3.3V power supply
    QSFP+ MSA compliant
    Up to 40km transmission
    Operating case temperature: 0~70C
    Maximum 3.5W operation power
    RoHS compliant
    Compliant with IEEE802.3ba
    Compliant with QSFP+ MSA: SFF-8436

    Applications:
    40G Ethernet
    Infiniband 4X SDR DDR QDR
    40G Telecom connections
